Konsola GPD WIN 4 2025 AMD Ryzen AI 9 HX 370 12 Cores Max 5 1GHz 32GB RAM 2TB SSD

Highlights

6-inch Screen

GPD WIN 4 2025 features a 6-inch eye-care screen with native landscape mode and a 1920x1080 resolution, 16:9 golden ratio, and 368 PPI. It supports two refresh rates - 60Hz and 40Hz. The screen is protected by the 5th generation Corning Gorilla Glass and has DC dimming with no flicker. It inherits the slide cover design from WIN 3, but with a larger screen, narrower bezels, and a wider field of view.

AMD Ryzen AI 9 HX 370 & AMD Radeon 890M

GPD WIN 4 2025 is equipped with AMD Ryzen AI 9 HX 370 CPU and AMD Radeon 890M GPU with 12 cores and 24 threads that can reach up to 5.1GHz, while the GPU’s 16 compute units can reach up to 2900MHz.

32GB LPDDR5x RAM 2TB SSD

GPD WIN Max 4 (2025) utilizes LPDDR5x 7500MT/s memory. Up to 16GB of this memory can be allocated to VRAM, allowing AI applications that require large VRAM to perform fully. Supports the PCIe Gen4×4 specification, with a theoretical maximum throughput of up to 7.877GB/s, with actual sequential read and write speeds exceeding 5000MB/s, allowing for unlimited expansion.

Oculink (SFF-8612) Female Port

The WIN 4 integrates an Oculink (SFF-8612) female port, providing PCIe direct connection with effective bandwidth of 63Gbps. It perfectly supports the GPD G1 mobile graphics dock, improving gaming experience and work efficiency

4G LTE Clip-On Module

To enable gaming on-the-go, WIN 4 comes with an exclusive 4G LTE clip-on module that supports global network coverage. This module supports 4G TD-LTE, FDD-LTE, and 3G CDMA networks and accommodates a Nano-SIM card. It is an optional module and not included as standard equipment. There is no need to disassemble the device as it can be easily clipped onto the back of the device when needed.

Two Customizable Physical Back Buttons

During gaming, the top cover of the device is typically not slid open. However, there are times when you need to press the Esc key to return to the game settings port, and sliding open the cover each time can be inconvenient. To address this, two customizable physical buttons have added on the back of the WIN 4 to easily customize combination keys and interval times.

L1 / R1 Trigger Buttons

The L1/R1 trigger buttons of the WIN 4 come equipped with LED ambient lighting, featuring seven-color LED backlight effects with customizable colors and multiple lighting modes to choose from. You can also adjust or turn off the lighting effects at any time using the built-in WinControls tool within the system.

Dual 3D Joysticks

WIN 4 returns to the traditional staggered layout for its joysticks, highlighting the externally mounted dual 3D joysticks manufactured by ALPS. These joysticks have a large range of motion and low resistance, sacrificing some response speed for improved precision. When playing fighting games, the joystick's comfort level is comparable to top-tier Japanese Shimizu and Sanwa joysticks, with native support for L3/R3 functions via joystick pushes.

6-Axis Gyroscope

The WIN 4 features built-in 6-axis gyroscope positioning, which can convert motion-controlled actions into various joystick button inputs. Human movements can determine the direction of the racing car, providing a deep experience of motion control. This translates into a wider range of gameplay options. The exclusive optimization tool, 'MotionAssistant', not only emulates the Xbox 360 joystick but also simulates native motion-controlled games on the PS4.

Dual Speakers

In terms of audio, the WIN 4 inherits its predecessor's excellent design, utilizing a high PSRR intelligent amplifier for improved efficiency and lower noise. It also retains the top-of-the-line German AAC stereo ultra-linear speakers, with a sound chamber that employs Bass materials, equivalent to a large 0.9cc sound chamber design. The dual-coil driven diaphragm ensures balanced force distribution, while double amplitude enhancement produces exceptionally loud sound.

Specification

General

Brand: GPD
Type: Handheld Game Laptop
Model: WIN 4 2025
Color: Black
OS: Pre-installed with Windows 11 Home 24H2

Display Touch Panel: Supports
Screen Type: Corning Gorilla Glass 5, H-IPS Technology
Screen Size: 6 Inches, Native Landscape Mode, DC Dimming
Aspect Ratio: 16:9
Screen Resolution: 1920*1080, 1280*720, Image resolution: 40Hz&60Hz
Pixels Per Inch: 368 PPI
CPU Model: AMD Ryzen AI 9 HX 370
Architecture: Zen 5 Zen 5C (Strix Point)
Cores/Threads: 12C/24T
Base Clock: 2.0GHz
Max. Boost Clock: 5.1GHz
AI Performance: 50 TOPS
Total Processor Performance: 80 TOPS
Total Cache: 36.75 MB
Process Size: 4nm
TDP: 15W-35W
GPU Processor Graphics: AMD Radeon™ 890M
Graphics Frequency: 2900 MHz
Compute Units: 16CU
Shading Units: 1024
Floating-point Performance: 23.76 TFlops (FP16), 11.88 TFlops (FP32), 742.4 GFlops (FP64)
Pixel Rate: 92.80 GPixel/s
Texture Rate: 185.6 GTexel/s
Storage Memory: 32GB
Memory Types: LPDDR5x 7500 MT/s
Memory Channel: Dual Channel
Hard Disk Type: M.2 SSD
Hard Disk Port: M.2 (Socket 3) x 1
Supported Specifications: M.2 NVMe 2280 x 1
Standard Capacity: 2TB x 1
Bus Specification: PCIe 4.0 x 4
Multimedia Support Audio System: Built-in Sound Chip Intelligent Amplifier That Features High Energy Efficiency, High PSRR and Low Noise
Loudspeakers: Built-in Dual Speakers
Microphone: Built-in Microphone
Network Communications

4G LTE Module:
Back-mount Module, Selectable
Type of SIM Card: Nano-SIM, Single
4G Network: TD-LTE, FDD-LTE
3G Network: WCDMA/TD-SCDMA/CDMA
2G Network: GSM
Frequency Band:
LTE-FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B28
LTE-TDD: B38/B39/B40/B41
UMTS: B1/B2/B4/B5/B6/B8/B9
GSM: B2/B3/B5/B8

Wi-Fi: Wi-Fi 6E(802.11ax) 2 x 2
MU-MIMO: Support
Bluetooth: 5.3

I/O Ports

Video/Data/Charging:
USB4, 40Gbps (Full Speed) x 1
USB 3.2 Gen 2 Type-C Full-featured, 10Gbps x 1
USB 3.2 Gen 2 Type-C Charging Only (Provided By The Dock) x 1
Oculink (SFF-8612) female port with a bandwidth of 63Gbps and a throughput of up to 7.877GB/s x 1
USB 3.2 Gen 2 Type-A, 10Gbps (Provided By The Dock) x 3
HDMI 2.0 (Provided By The Dock) x 1

microSDXC Slot:
Bus Port: UHS-I
Speed Class: Class 10
Ultra High Speed: U3
Video Speed Class: V30
Application Performance Class: A2
Read/Write: 160MB/s, 90MB/s
Maximum Capacity: 2TB

Ethernet Ports: RJ45 (Provided By The Dock) x 1
Audio Port: 3.5mm Headphone/Microphone Combo Port, Compatible With Apple Headphones (US Specification) x 1
BIOS Reset Port: Supports

I/O Device Keyboard: QWERTY Full Keyboard Design, Scissor-Switch Keys, White Backlight, And Combination Keys For On/Off Function
Mouse: Mouse 1: Right Joystick Simulates Mouse, Requires Switching Between "Gamepad/Mouse" Mode; Mouse 2: Optical Finger Mouse With Support For Click Confirmation Via Pressure
Fingerprint Recognition: Yes
Joystick: ALPS OEM Dual 3D Joysticks With Native Support For L3/R3 Via Downward Press
D-Pad: Siamese Cross Key
Game Function Buttons: ABXY, △○×□ Double Character Print, Select, Start, Xbox Controller Home
Game Accessories Buttons: L1/R1 Feature Rainbow Lighting Design, While L2/R2 Are Linear Analog Buttons
Handle Vibration: Dual Vibration Motors, Software Controlled, Capable Of: Turning Off, Weak Vibration, Strong Vibration
Dorsal Key: Two Back Buttons, Mappable And Programmable
Other Keys: Volume /- Buttons, Power Button, Gamepad/Mouse Mode Switch
Sensor: 6-axis Design: 3-axis G-sensor, 3-axis Gyro
Speaker: 2 Pcs
Indicator Lamp: Charging Indicator, Running Indicator
Battery Battery Type: Li-polymer
Battery Capacity: 45.62Wh
Battery Life: 2 Hours Of Heavy Use, 3-6 Hours Of Moderate Use, 10 Hours Of Light Use, Depending On The Specific Environment Of Use
Weight & Size Product Weight: 0.598kg
Package Weight: 1.31kg
Product Size(L x W x H): 22 x 9.2 x 2.8cm
Package Size(L x W x H): 25.8 x 19.7 x 5.6cm
Package Contents

1 x WIN 4 2025 Handheld Game Laptop
1 x 65W Power Adapter
1 x Warranty Card
1 x User Manual
